Product Name:
Specification: 0.8MM, 1.0MM, 1.2MM
Delivery Time:15 days
Payment Term: T/T or L/C
Enquire NowThe E71T-1 gas shielded mild steel flux cored wire is the superior titanium slag offering stable welding, smooth arc, low spatter, high slag detachability and flawless bead. This CO2 flux cored wire is also endowed with outstanding mechanical property with low diffusible hydrogen level ≤5ML/100G.
Our Flux Cored Wire is well-suited for welding mild steel and low alloy with 500Mpa tensile strength. This welding consumable is typically used in shipbuilding, bridge, general fabrication, storage vessel and boiler, as well as all structural steel erection.
Standards:
GB/T10045-2001 E501T-1
AWS A5.20 E71T-1
Chemical Composition of deposited metal(%)
C | Mn | Si | P | S | |
Standard | ≤0.18 | ≤1.75 | ≤0.90 | ≤0.03 | ≤0.03 |
Typical | 0.07 | 1.25 | 0.36 | 0.016 | 0.012 |
Mechanical Properties of Deposited Metal
Rm (Mpa) | Rp(Mpa) | A5(%) | Akv(J)(-20℃) | |
Standard | 490-660 | ≥400 | ≥22 | ≥27 |
Typical | 570 | 490 | 28 | 100 |
Recommended Welding Data (DC+, Shielding Gas: CO2):
Wire Diameter(mm) | Current(A) | Voltage(V) | Gas(L/Min) |
1.2 | 140-300 | 20-30 | 15-25 |
1.4 | 200-320 | 24-32 | 15-25 |
1.6 | 240-360 | 26-34 | 15-25 |
Characteristics and Applications:
1. Used for Welding Sheet Metal in all Positions
2. Used for High Efficiency Welding in all Positions
3. Used for High Efficiency Welding of Ships, Bridges, Vehicles and so on
4. Used in Flat position and Horizontal Fillet welding, it can continuously weld three layers before cleaning slag, it has good performance in anti-blowhole.
5. Used for welding very important low carbon steel and low alloy steel with corresponding strength grade.
